Test results are only as accurate as the equipment used to get those results. Load frames that are well-maintained produce more accurate and repeatable test results, giving you the peace of mind that comes with knowing that you can trust your data. Rely on MTS to perform the checks and adjustments necessary to get the best results possible from your load frame tests.
On a routine maintenance visit, MTS field service engineers check the entire electromechanical system: the hardware, software and electronics. We lubricate bearings and ball screws, back up specific testing software files, check cables and connections and verify overall system performance. At the end of each routine maintenance visit, we’ll provide a report of all services performed, current equipment condition and any recommendations, if necessary.
MTS Criterion Electromechanical Load Frame
Recommended service to be performed at each running time interval noted
Calendar Time Using 8 Hour Run Time Rate Per Day
Daily
Weekly
Annually
Running Time - Hours
8
40
2,000
Shunt Cal Check
X
Clean Work Area / Machine Surface
X
Verify Limits and E-Stop
X
Inspect Cable / Connections
X
PC Maintenance
Back up Testing Software Files (*.reg/cal files)
MTS
HD Defragmentation
MTS
System Inspection
Check / Adjust Drive Belt Tension
MTS
Inpect Drive Belts for Excessive Wear
MTS
Inspect Cable Connections
MTS
System Checks
Check E-Stop
MTS
Check Upper Limit
MTS
Check Lower Limit
MTS
Check Load Cal / Shunt Cal
MTS
Lubrication
Crosshead / Ball Screw
MTS
Guide Column Zerk Fittings
MTS
Drivetrain Bearings (if applicable)
MTS
Frame and Work Area
Clean Frame and Work Area
MTS
Note: MTS
Symbol denotes service performed by trained field service engineers as part of an MTS Routine Maintenance plan. Some of these procedures require special service tools and/or specific service training to complete.
Note: X
Symbol denotes services performed by equipment operators. Most of these procedures involve visual checks that should not interfere with test system operation. These checks are also completed by trained field service engineers on each Routine Maintenance visit.
MTS Criterion Static-Hydraulic Load Frame
Recommended service to be performed at each running time interval noted
Calendar Time Using 8 Hour Run Time Rate Per Day
Daily
Weekly
Annually
Running Time - Hours
8
40
2,000
Shunt Cal Check
X
Clean Work Area / Machine Surface / Jaw
X
Verify Limits and E-Stop
X
Inspect Cable / Connections
X
PC Maintenance
Back up Testing Software Files (*.reg/cal files)
MTS
HD Defragmentation
MTS
System Inspection
Inspect / Clean Controller
MTS
Inspect Cable Connections
MTS
System Checks
Check E-Stop
MTS
Check Piston Travel Limit
MTS
Check Crosshead Upper Limit
MTS
Check Crosshead Lower Limit
MTS
Check Load Cal / Shunt Cal
MTS
Check Load Cal / Shunt Cal
MTS
Lubrication
Cushion Plates and Wearable Plates of the Grip
MTS
Driven Parts of Lower Crosshead
MTS
Frame and Work Area
Clean / Replace Air Filter
MTS
Clean / Replace Suction Filter
MTS
Clean / Replace High-pressure Line Filter
MTS
Note: MTS
Symbol denotes service performed by trained field service engineers as part of an MTS Routine Maintenance plan. Some of these procedures require special service tools and/or specific service training to complete.
Note: X
Symbol denotes services performed by equipment operators. Most of these procedures involve visual checks that should not interfere with test system operation. These checks are also completed by trained field service engineers on each Routine Maintenance visit.
