These 10 kN Screw Action Grips allow specimen loading from the side for better test performance. A centering device provides fast and accurate specimen positioning.
» Quick-acting U-shaped grips allow specimen loading from the side for better test performance
» Centering device provides fast and accurate specimen center force axis positioning
» Switching structure allows faces to be moved synchronously or separately
» Optional faces are available for a variety of specimens, upon request
10 kN Screw Action Grip
Specifications
Model
DX104A
Part Number
100-302-665
Rated Force
10 kN (2,250 lbf)
Temperature Range
Room temperature
Weight
(Upper grip)
9.80 kg (21.6 lb)
(Lower grip)
9.80 kg (21.6 lb)
Adapter style
(Upper grip)
20 mm (0.8 in)
(Lower grip)
20 mm (0.8 in)
Dimensions (h*w*d)
(Upper grip)
164 mm × 250 mm × 72 mm (6.5 in x 9.8 in x 2.8 in)
(Lower grip)
164 mm × 250 mm × 72 mm (6.5 in x 9.8 in x 2.8 in)
